◆產品設備結構特征 Product features
1. 規劃刺激,外型精美,安全使用性能好;
2. 調節器式風暴分離處理出來器,能將能夠用研磨材料磨具與小煙塵分離處理出來,好的研磨材料磨具一直安全使用;
3. 最主要的零安全裝置通過高質量進囗的零配件,使用的生存期長;
4. 制造鋼件從表面平滑;
5. 多工作臺面設置;控制員可互相控制噴砂。基于用戶需要量,先選擇帶有大量手動或一鍵 ;可按客服符合要求生產廠家!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆采用超范圍 Applicable scope
鋼板,網上表殼,功放音響開關面板,三文治烤盤等水平及方體產品的噴砂工藝。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆最主要科技參數指標 Main technical parameters
機子技術參數 Model |
STR-多工位輸送式噴砂機 |
整套裝置寬度 Complete machine size(mm) |
3000×1000×1700 |
作業三維空間 Work space(mm) |
2000×1000×800 |
外氣流輸送圖片尺寸 Conveying the size(mm) |
500×1000×1000(2件) |
抑塵箱長寬比 Dedust box sizes(mm) |
600×600×1800 |
脫離器三相異步電機 Separator motor |
220V 50HZ 550W |
剝離 器風口尺寸 Separator air volume |
8.5m3/min |
解壓縮氧氣源 Compressed air source |
2-8bar(kg/cm2) |
噴槍 Spray gun |
2把 |
照明 Floodlight |
兩盞30W防燃燈 |
設備體重 Machine weight |
550kg |
