STR-環保風力循環回收式噴砂房效果圖

STR-Environmental protection wind cycle recovery sandblast room designsketch

◆噴砂（丸）房的成分模式

Composition of the sandblasting (shot) room system

1、運行室  Studio

2、噴砂系統的  Sandblasting  system

3、金剛石工具回收公司系統  Abrasive recycle system

4、除塵器操作系統  Dust removal system

5、鏜孔卸料系統性  Workpiece conveying system

6、操縱系統  Control system

7、照明工程軟件  Lighting system

 ◆采用領域 Applicable scope

中型鑄件鍛件、焊接加工鋼結構網架類型、電壓器汽車油箱、水利自動化機械廠、電力機車車子、電爐打造、所有自動化機械廠、船只修造等噴砂防銹。

Large castings and forgings welding steel structure, transformer oil tank, engineering machinery, locomotives, boiler manufacturing, chemical machinery, ship building blast cleaned, etc.

 ◆服務的特點 Product features

噴砂房是我公司在蜂窩地板技術的基礎上，自行開發、設計的環保型蜂窩式噴砂（丸）房，可按客戶的產品特性、噴砂要求等設計制作。蜂窩地板噴砂房是利用風機的風力為動力，將磨料通過回料管道吸送到旋風分離器中進行分離，最后進入噴砂系統循環利用。

Sandblasting room  is our company in introducing foreign advanced cell technology based on the floor, , the development, the design of the environmental protection cellular gush arenaceous (shot) room by ourselves, according to customers' product characteristics, sandblasting design requirements, etc. Cellular floor gush arenaceous room is the wind power by fan for abrasive materials, will back through the pipe to cyclone separator suction of separation and finally into gush arenaceous system recycling.

兼具以上顯著優點：

1、省去了常規噴砂房砂料輸送煤循環系統的螺旋輸送機，斗式提升機以及地下工程，不需建造地坑，節約了地基施工費用，大大節約了工程成本；

2、爐料的回收利用率高，方便于清換爐料；

3、包括電子商務電氣元件均選用進口清關新產品，兼備機械性能維持，安全衛生能信，便用蓄電量長，保護簡易；

4、噴砂房室體內有高清晰的能見度，室體自然補風，節約能源消耗；

5、該機應用雙極布袋吸塵，一是級應用漩風隔離器，最后級用空氣濾芯式布袋吸塵裝置，其總布袋吸塵能力達到99.99%以上內容；

6、在噴砂房正面房頂上部，配有“聲光報警系統”，在噴砂房內，配有急停呼叫按鈕；

7、各體統電氣掌控用互鎖掌控，當其中的一體統經常出現機械故障時，各種相關體統均關閉程序任務，噴槍關閉程序噴射；

8、房體進行建筑結構裝潢開發，金屬機身簡約、牢固、正確，隔音降噪效果更好好，且裝簡單。

Advantages

1. Omitted conventional Sandblasting room sand conveying coal circulation system, screw conveyor a pattern lift machine and underground project, no need to build the pit and save foundation pit construction cost, greatly reduce the project cost;

2. high  abrasive recycle efficiency, easy to change abrasive;

3. The main electrical components are imported products, have the stable performance, safety and reliability, long life, easy maintenance;

4. Sandblasting room inside has high-resolution visibility, Chambers fill the wind, save energy natural consumption;

5. This machine use double levels of dust removing, the first level is the cyclone separator, the second type is filter dust removal system. Its total removal efficiency may reach above 99.99%;

6. In sandblasting room roof, equipped with a "positive upper sound-light alarm system", in the room, sandblasting with abrupt stop call button;

7. The electric control system uses interlock control, while one system malfunction, related system are to stop working, stop spraying gun;

8. Building decoration design room body appearance, simple , beautiful, standard, good noise reduction result  and convenient installation.
