◆高技術性能指標 Main technical parameters (請往上面瀏覽器大有量典例圖片視頻供考生)
儀器型號 Model |
STR-9070/9080 |
STR-1010 |
事業艙面積 Internal size(mm) |
900×800×650 |
1000×1000×790 |
機床尺寸 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
電源線 Power |
220V 50Hz |
220V 50Hz |
儀器燈具照航燈 Machine floodlight |
那盞60W防爆型燈 |
220V 13W節能減排燈 |
滾筒軸承受 Roller bearing |
10-30Kg |
10-30Kg |
離心過濾器原理調速電機 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
分開器新風量 Separator air volume |
8.5m3/min |
8.5m3/min |
減少氣體源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
儀器克重 Weight |
320kg |
380 kg |
◆成品結構特征 Product features
1. 設計的貼近生活、形象大度、結構特征實驗、操作流程便捷;
2. 自功操控自功噴砂,具備定時噴砂,點動標記等的功能;
3. 滾簡外徑及噴槍用量可表明業主需要的設計定制;
4. 就可以人工手動開啟機組,又可自功,噴砂的質量好,一機有很多用途。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆適用人群范疇 Applicable scope
可用以于多小部件的手動或一鍵噴砂,列舉:電竹木品、螺釘、塑料制品制
品、鈕扣、拉鏈頭、亞克力、廣州POS機零控制部件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
